Philmac BSP Large Bore Fittings
Philmac’s robust range of large bore threaded fittings provide precision BSP tapered threads that have been engineered to maximise sealing performance.
The versatile range is made from high performance, UV resistant polypropylene that does not absorb moisture. Installation is quick, simple and reliable every time. The material is also potable water (AS/NZ 4020) approved.
Philmac’s threaded fittings provide maximum versatility, delivering a high performance connection across a wide range of pressure ratings and chemical combinations. The hexagonal body makes them extremely simple to install. Importantly, Philmac threaded fittings are suitable for working pressures up to PN16 for sizes up to 2”, PN12 for 2-1/2” and PN10 for 3” and 4” sized fittings.
PHILMAC PLUGS LARGE BORE
| Product Number | Size |
|---|---|
| 90407700 | 2-1/2″ |
| 90408800 | 3″ |
| 90400000 | 4″ |
PHILMAC BUSHES LARGE BORE
| Product Number | Size |
|---|---|
| 90417400 | 2-1/2″x 1-1/4″ |
| 90417500 | 2-1/2″x 1-1/2″ |
| 90417600 | 2-1/2″x 2″ |
| 90418500 | 3″x 1-1/2″ |
| 90418600 | 3″ x 2″ |
| 90418700 | 3″ x 2-1/2″ |
| 90410600 | 4″ x 2″ |
| 90410700 | 4″ x 2-1/2″ |
| 90410800 | 4″ x 3″ |
PHILMAC NIPPLES LARGE BORE
| Product Number | Size |
|---|---|
| 90427400 | 2-1/2″ x 1-1/4″ |
| 90427500 | 2-1/2″ x 1-1/2″ |
| 90427600 | 2-1/2″ x 2″ |
| 90428500 | 3″ x 1-1/2″ |
| 90428600 | 3″ x 2″ |
| 90428700 | 3″ x 2-1/2″ |
| 90428800 | 3″ |
| 90420600 | 4″ x 2″ |
| 90420700 | 4″ x 2-1/2″ |
| 90420800 | 4″ x 3″ |
| 90420000 | 4″ |
PHILMAC SOCKETS LARGE BORE
| Product Number | Size |
|---|---|
| 90437500 | 2-1/2″ x 1-1/2″ |
| 90437600 | 2-1/2″ x 2″ |
| 90437700 | 2-1/2″ |
| 90438600 | 3″ x 2″ |
| 90438700 | 3″ x 2-1/2″ |
| 90438800 | 3″ |
| 90430700 | 4″ x 2-1/2″ |
| 90430800 | 4″ x 3″ |
| 90430000 | 4″ |
PHILMAC TEES FI LARGE BORE
| Product Number | Size |
|---|---|
| 90457700 | 2-1/2″ |
| 90458800 | 3″ |
| 90450000 | 4″ |
PHILMAC ELBOWS FI LARGE BORE
| Product Number | Size |
|---|---|
| 90467700 | 2-1/2″ |
| 90468800 | 3″ |
| 90460000 | 4″ |
PHILMAC CAPS LARGE BORE
| Product Number | Size |
|---|---|
| 90490700 | 2-1/2″ |
| 90490800 | 3″ |
| 90490000 | 4″ |
Overview / Why Choose This Product
Philmac BSP Large Bore Fittings are engineered for heavy-duty water transfer applications, providing secure, leak-free threaded connections in large-diameter pipelines. Ideal for irrigation, pump stations, and industrial fluid handling, these fittings combine strength, corrosion resistance, and ease of installation. Built tough for Australian conditions, they resist UV degradation and harsh environments. Australian Made quality ensures confidence in every connection.
Key Features
Heavy-duty BSP threads – for secure, leak-free performance in large bore systems
Durable construction – UV-stabilised and corrosion-resistant
High-volume capability – designed for large-diameter pipelines
Easy handling – lightweight yet strong for easier installation
Applications & Benefits
Applications
- Irrigation pump stations
- High-volume water transfer systems
- Industrial fluid handling
- Large-scale agricultural installations
Benefits
- Reliability – engineered threads reduce leaks and downtime
- Durability – withstands UV exposure and harsh conditions
- Versatility – available in multiple configurations for large bore systems
Technical Specifications
- Size Range: 4″ – 6″ BSP
- Thread Type: BSP (British Standard Pipe)
- Pressure Rating: Up to PN16
- Material: High-grade UV-stabilised polypropylene
- Potable Water: Suitable where compliant; confirm local regulations
- Temperature & Chemical Suitability: Refer to datasheet for operating limits
Note: Always confirm size, pressure class, and compliance requirements against the official datasheet and local standards.
Installation Guide
- Ensure threads are clean and free from debris.
- Apply thread sealant or tape as per best practice.
- Hand-tighten, then wrench-tighten to recommended torque.
- Pressurise and test the system before commissioning.
For detailed diagrams and torque guidance, view the Philmac installation guide online.
FAQs
What thread type do these fittings use?
Philmac BSP Large Bore Fittings use British Standard Pipe (BSP) threads.
Are they suitable for potable water?
Yes, where compliant. Always confirm local regulations and product datasheet.
Do I need thread tape or sealant?
Yes. Use appropriate thread sealant or PTFE tape for leak-free performance.
What sizes and configurations are available?
Common sizes include 4″ and 6″ BSP, with options such as sockets, elbows, and caps.
