Philmac Filters

Filters remove impurities and sediment from fluid in a pipeline system. Over time sediment can build up and reduce the overall performance of a system and block water delivery through sprinklers and emitters.

Send an Enquiry

Range Downloads Installation

Type

Elbow Female BSP Joiner Male BSP Reducing Spare Part Tee Valve End Cap Bush Barb Clamp Spray Dripper Stake Filter Coupling Socket Nipple Ball Valve Float Valve End Plug Float Nut Pod Kit Riser Adapter

Australian Made

Any Yes No

Warranty

Any None 20-year

Certification

Any WaterMark ASN 4020

Filter Clear

DISK FILTERS 1″



Product Number	Size
L-830123	1” disk filter (large)
L-830153	1” disk filter (large)

DISK FILTERS 1″ HIGH FLOW RATE



Product Number	Size
L-860123	1” disk filter (special)

DISK FILTERS 1-1/2″



Product Number	Size
L-860156	1-1/2” disk filter
Maximum operating pressure of 3/4”, 1” & 11/4” Disk Filters is 6 bar (87 psi).
Maximum operating pressure of 11/2” Disk Filters is 8 bar (116 psi).

DISK FILTERS 1-1/4″

Product Number	Size
L-860154	1-1/4” disk filter (special)

DISK FILTERS 3/4″

Product Number	Size
L-830122	3/4” disk filter (large)

SCREEN FILTERS 1″



Product Number	Size
L-820063	1” screen filter (large)
L-820083	1” screen filter (large)
L-820123	1” screen filter (large)
L-820153	1” screen filter (large)

SCREEN FILTERS 1″ HIGH FLOW RATE



Product Number	Size
L-840083	1” screen filter (special)
L-840123	1” screen filter (special)
L-840153	1” screen filter (special)
L-840183	1” screen filter (special)

SCREEN FILTERS 1-1/2″



Product Number	Size
L-870065	1-1/2” screen filter
L-870085	1-1/2” screen filter
L-870125	1-1/2” screen filter
L-870155	1-1/2” screen filter

SCREEN FILTERS 1-1/4″



Product Number	Size
L-840084	1-1/4” screen filter (special)
L-840124	1-1/4” screen filter (special)
L-840154	1-1/4” screen filter (special)
L-840184	1-1/4” screen filter (special)

SCREEN FILTERS 2″





Product Number	Size
L-870066	2” screen filter
L-870086	2” screen filter
L-870126	2” screen filter
L-870156	2” screen filter
Maximum operating pressure of 3/4”, 1” & 11/4” Screen Filters is 6 bar (87 psi).
Maximum operating pressure of 11/2”, 2” Screen Filters is 8 bar (116 psi).

SCREEN FILTERS 3/4″



Product Number	Size
L-820062	3/4” screen filter (large)
L-820082	3/4” screen filter (large)
L-820122	3/4” screen filter (large)

HYDRACYCLONE SCREEN FILTERS 1-1/2″

Product Number	Size
L-880065	1-1/2” Hydro-cyclone
L-880085	1-1/2” Hydro-cyclone
L-880125	1-1/2” Hydro-cyclone
L-880155	1-1/2” Hydro-cyclone

HYDRACYCLONE SCREEN FILTERS 2″

Product Number	Size
L-880066	2” Hydro-cyclone
L-880086	2” Hydro-cyclone
L-880126	2” Hydro-cyclone
L-880156	2” Hydro-cyclone
Maximum operating pressure of 11/2” and 2” Hydrocyclone Screen Filters is 8 bar (116 psi).
Hydrocyclone Screen Filters are supplied with Flush Valve.

FIP PVC SEDIMENT STRAINERS





Product Number	Size
RVULV050E	1/2”
RVULV075E	3/4”
RVULV100E	1”
RVULV125E	11/4”
RVULV150E	11/2”
RVULV200E	2”
Strainers supplied with 35 Mesh / 500 Micron PVC Strainer Element

FIP TRANSPARENT PVC RV SEDIMENT STRAINERS

Product Number	Size

RVUFT050E	1/2”
RVUFT075E	3/4”
RVUFT100E	1”
RVUFT125E	11/4”
RVUFT150E	11/2”
RVUFT200E	2”
Strainers supplied with 35 Mesh / 500 Micron PVC Strainer Element

Philmac Filters

Technical

Philmac Filters

Brochure

Philmac Filters

Range

Overview / Why Choose This Product

Philmac Filters are designed to protect irrigation and water transfer systems by removing debris and preventing blockages. Available in screen and disc configurations, these filters deliver consistent performance and easy maintenance. Built tough for Australian conditions, they resist UV and corrosion for long-term reliability. Australian Made quality ensures confidence in every installation.

Key Features

Effective filtration – protects pumps, valves, and emitters from debris

Easy maintenance – quick access for cleaning and servicing

Durable construction – UV-stabilised polypropylene body

Multiple filtration grades – options to suit system requirements

Applications & Benefits

Applications

• Drip and micro-irrigation systems
• Pump and water transfer setups
• Agricultural and horticultural watering
• Domestic and commercial irrigation

Benefits

• System protection – reduces blockages and downtime
• Improved efficiency – maintains consistent flow and pressure
• Built tough – withstands harsh conditions and UV exposure

Technical Specifications

• Size Range: ¾” – 2″ BSP
• Filter Types: Screen and disc
• Filtration Grades: Common options include 120, 200, and 400 micron
• Material: UV-stabilised polypropylene body

Note: Always confirm size, filtration grade, and compliance requirements against the official datasheet and local standards.

Installation Guide

1. Install filter upstream of irrigation emitters or sensitive equipment.
2. Ensure correct orientation for flow direction (marked on body).
3. Apply thread sealant or tape as per best practice.
4. Pressurise and test the system before commissioning.

For detailed cleaning instructions and maintenance intervals, view the Philmac installation guide online.
