Philmac Micro Irrigation Spray

Precision water delivery to maximise coverage

With a diverse range of full and part-circle sprays they are perfectly suited to a range of garden bed shapes and sizes for both domestic and commercial applications. There are also options for the professional horticulturist. With advances in manufacturing technology the range now features the option of pressure compensating sprays to deliver the precise volume of water every time.  Plus there are variable discharge options to optimise the volume of water for different sized plants.

Send an Enquiry

Range Downloads Installation

Type

Elbow Female BSP Joiner Male BSP Reducing Spare Part Tee Valve End Cap Bush Barb Clamp Spray Dripper Stake Filter Coupling Socket Nipple Ball Valve Float Valve End Plug Float Nut Pod Kit Riser Adapter

Australian Made

Any Yes No

Warranty

Any None 20-year

Certification

Any WaterMark ASN 4020

Filter Clear

PHILMAC XL-JET GARDEN SPRAY



Product Number	Size
SF3617	360° Orange
	140 L/h @ 150 kPa
SF1812	180° Green
	70 L/h @ 150 kPa
SF9009	90° Black
	35 L/h @ 150 kPa
Matched Precipitation – provide uniform coverage – 360° is double the flow of 180° which is double the flow of the 90° unit

PHILMAC XL-JET GREEN HOUSE MISTER

Product Number	Size
MXL09	Black – 35 L/h @ 150 kPa

PHILMAC XL-JET STRIP SPRAY



Product Number	Size
SXL12	Green – 3.2 m rad. x 1.1 m wide
	70 L/h @ 150 kPa
SXL14	Red – 3.7 m rad. x 1.1m wide
	90 L/h @ 150 kPa

ONE PIECE SPRAY





Product Number	Size
JSF12	360° Green
	1.2 m radius – 55 L/h @ 100 kPa
JSH12	180° Green
	1.2 m radius – 55 L/h @ 100 kPa
JSQ12	90° Green
	1.2 m radius – 55 L/h @ 100 kPa
JSF16	360° Black
	1.5 m radius – 90 L/h @ 100 kPa
JSH16	180° Black
	1.5 m radius – 90 L/h @ 100 kPa
JSQ16	90° Black
	1.6 m radius – 90 L/h @ 100 kPa

STRIP SPRAY-BOWTIE PATTERN

Product Number	Size
DV16/T	Blue -1.9 m radius x 1.4 m max width

TWO PIECE SPRAY-STRIP PATTERN



Product Number	Size
M220	Blue – 2 x 20° strips
	2.9 m radius – 33 L/h @ 100 kPa

HOLE PUNCH

Product Number	Description
PK4	Punch Spanner for 1 piece jets

Philmac Micro Spray

Technical

Philmac Vortex 360 End-Line Spike

Technical

Philmac XL Jet Spray

Technical

Filmac J-Series Fan Jets

Technical

Philmac Micro Spray

Technical

Overview / Why Choose This Product

Philmac Micro Irrigation Sprays are designed for efficient water distribution in low-flow systems. With a range of spray patterns and flow rates, these sprays provide targeted coverage for gardens, landscapes, and horticultural applications. Manufactured from UV-stabilised polypropylene, they resist corrosion and withstand harsh outdoor conditions.

Key Features

Targeted water distribution – multiple spray patterns for flexibility

UV-stabilised polypropylene – engineered for outdoor use

Wide range of flow rates – suitable for various irrigation needs

Easy installation – push-fit or threaded options

Applications & Benefits

Applications

• Garden beds and pots
• Landscaping projects
• Horticultural irrigation
• Greenhouse setups

Benefits

• Efficient water use – reduces waste and improves plant health
• Quick installation – saves time during setup
• Long service life – withstands UV exposure and corrosion

Technical Specifications

• Flow Rates: 20 L/h to 120 L/h
• Spray Patterns: Full circle, half circle, quarter circle, strip
• Connection Type: Barbed or threaded ends
• Material: UV-stabilised polypropylene

Note: Always confirm flow rate and compatibility against the official datasheet and local standards.

Installation Guide

1. Select correct spray type (pattern and flow rate) for your irrigation layout.
2. Cut micro tubing square and ensure ends are clean.
3. Insert spray barbed end fully into tubing for a secure fit.
4. Position spray upright for optimal coverage.
5. Pressurise and test the system for leaks and correct spray pattern.

For detailed diagrams and adjustment tips, view the Philmac installation guide online.
