Philmac OptiPHIL
With a new compact arm design, the dedicated OptiPHIL Above Water valve will allow for minimal/zero air gap in above-water installations and an arm extension for even more water level flexibility.
The Smooth-Flo design optimises water flow out of the valve, reducing turbulence, minimising float bounce, cutting water spray, and saving your pump.
Patent protected, Opti-Flo technology, optimises water flow through the valve to help prevent blockages & improve performance in dirty water. While patent protected, soft closing design provides a reliable shut-off & prevents damaging water-hammer.
OptiPHIL is a full flow design, providing flows up to 847 L/min, and preventing pump short cycling, saving your pump and energy.
OptiPHIL Float Valve – Above Water
| Product Number | Size |
|---|---|
| 93600110 | 3/4″ and 1″ |
OptiPHIL Float Valve – Below Water
| Product Number | Size |
|---|---|
| 93600120 | 3/4″ and 1″ |
Overview / Why Choose This Product
Philmac OptiPHIL® is engineered for high-performance water level control, offering superior flow rates and precision adjustment for tanks and troughs. Ideal for agricultural and rural water systems, OptiPHIL® combines robust construction with corrosion-resistant internals for long-term reliability. Built tough for Australian conditions, it ensures consistent water supply where it matters most. Australian Made quality guarantees confidence in every installation.
Key Features
High-flow capacity – optimised for rapid filling and efficient water delivery
Precision control – adjustable float arm for accurate water levels
Durable construction – UV-stabilised polypropylene body
Corrosion-resistant internals – brass or stainless steel for longevity
Applications & Benefits
Applications
- Rainwater tanks
- Livestock watering troughs
- Agricultural reservoirs
- Irrigation header tanks
Benefits
- Consistent water levels – reduces manual monitoring
- Reliable performance – engineered for harsh conditions
- Long service life – withstands UV exposure and rough handling
Technical Specifications
- Size Range: ½” – 2″ BSP inlet
- Connection Type: BSP threaded ends
- Pressure Rating: Up to PN16
- Material: UV-stabilised polypropylene body with brass or stainless steel components
Note: Always confirm size, pressure class, and compliance requirements against the official datasheet and local standards.
Installation Guide
- Attach valve to tank or trough inlet using BSP threaded connection.
- Connect float arm and adjust position for desired water level.
- Pressurise and test the system for correct operation.
- Fine-tune settings for optimal performance.
For detailed diagrams and adjustment tips, view the Philmac installation guide online.
FAQs
What is OptiPHIL® used for?
OptiPHIL® is designed for high-flow water level control in tanks, troughs, and reservoirs.
What sizes are available?
Common inlet sizes include ½”, ¾”, 1″, 1½”, and 2″ BSP.
Do I need special tools for installation?
No. Installation is simple with standard plumbing tools.
