Philmac Rural Compression Fitting

The connection you can trust for connecting Rural B pipe

The Philmac Rural range of Australian made compression fittings provides the perfect connection for Australian Rural B Class poly pipe. Installation is easy with a simple to use insert assembly, and the fitting allows for straight forward disconnection and reconnection.

The Philmac Rural compression fitting range has been manufactured from high performance advanced thermoplastic materials so it is resisitant to corrosion and has the strength and durability to provide a long service life.

Send an Enquiry

Range Downloads Installation

Type

Elbow Female BSP Joiner Male BSP Reducing Spare Part Tee Valve End Cap Bush Barb Clamp Spray Dripper Stake Filter Coupling Socket Nipple Ball Valve Float Valve End Plug Float Nut Pod Kit Riser Adapter

Australian Made

Any Yes No

Warranty

Any None 20-year

Certification

Any WaterMark ASN 4020

Filter Clear

RURAL JOINER POLY x POLY





Product Number	Size
70 7111 00	1/2”
99 8121 00	3/4” x 1/2”
99 8122 00	3/4”
99 8132 00	1” x 3/4”
99 8133 00	1”
99 8143 00	11/4” x 1”
99 8144 00	11/4”
99 8154 00	11/2” x 11/4”
99 8155 00	11/2”
99 8165 00	2” x 11/2”
99 8166 00	2”

RURAL END CONNECTOR POLY x MI BSP

Product Number	Size
70 7211 00	1/2” x 1/2”
70 7212 00	1/2” x 3/4”
99 8221 00	3/4” x 1/2”
99 8222 00	3/4” x 3/4”
99 8232 00	1” x 3/4”
99 8233 00	1” x 1”
99 8243 00	11/4” x 1”
99 8244 00	11/4” x 11/4”
99 8253 00	11/2” x 1”
99 8254 00	11/2” x 11/4”
99 8255 00	11/2” x 11/2”
99 8256 00	11/2” x 2”
99 8265 00	2” x 11/2”
99 8266 00	2” x 2”

RURAL END CONNECTOR POLY x FI BSP

Product Number	Size
70 7811 00	1/2” x 1/2”
70 7812 00	1/2” x 3/4”
99 8821 00	3/4” x 1/2”
99 8822 00	3/4” x 3/4”
99 8832 00	1” x 3/4”
99 8833 00	1” x 1”
99 8843 00	11/4” x 1”
99 8844 00	11/4” x 11/4”
99 8854 00	11/2” x 11/4”
99 8855 00	11/2” x 11/2”
99 8865 00	2” x 11/2”
99 8866 00	2” x 2”

RURAL TEE POLY x POLY x POLY

Product Number	Size
70 7311 00	1/2” x 1/2” x 1/2”
99 8322 00	3/4” x 3/4” x 3/4”
99 8332 00	1” x 1” x 3/4”
99 8333 00	1” x 1” x 1”
99 8334 00	1” x 1” x 11/4”
99 8343 00	11/4” x 11/4” x 1”
99 8344 00	11/4” x 11/4” x 11/4”
99 8353 00	11/2” x 11/2” x 1”
99 8354 00	11/2” x 11/2” x 11/4”
99 8355 00	11/2” x 11/2” x 11/2”
99 8363 00	2” x 2” x 1”
99 8364 00	2” x 2” x 11/4”
99 8365 00	2” x 2” x 11/2”
99 8366 00	2” x 2” x 2”

RURAL TEE POLY x POLY x MI BSP

Product Number	Size
99 8931 00	1” x 1” x 1/2”
99 8932 00	1” x 1” x 3/4”

RURAL TEE POLY x POLY x FI BSP



Product Number	Size
70 7411 00	1/2” x 1/2” x 1/2”
99 8421 00	3/4” x 3/4” x 1/2”
99 8422 00	3/4” x 3/4” x 3/4”
99 8431 00	1” x 1” x 1/2”
99 8432 00	1” x 1” x 3/4”
99 8433 00	1” x 1” x 1”
99 8442 00	11/4” x 11/4” x 3/4”
99 8443 00	11/4” x 11/4” x 1”
99 8444 00	11/4” x 11/4” x 11/4”
99 8454 00	11/2” x 11/2” x 11/4”
99 8455 00	11/2” x 11/2” x 11/2”
99 8465 00	2” x 2” x 11/2”
99 8466 00	2” x 2” x 2”

RURAL ELBOW POLY x POLY



Product Number	Size
70 7511 00	1/2”
99 8522 00	3/4”
99 8533 00	1”
99 8544 00	11/4”
99 8555 00	11/2”
99 8566 00	2”

RURAL ELBOW 45° POLY x POLY

Product Number	Size
99 8028 00	3/4”
99 8038 00	1”
99 8048 00	11/4”
99 8058 00	11/2”
99 8068 00	2”

RURAL ELBOW POLY x MI BSP

Product Number	Size
99 8721 00	3/4” x 1/2”
99 8722 00	3/4” x 3/4”
99 8731 00	1” x 1/2”
99 8732 00	1” x 3/4”
99 8733 00	1” x 1”
99 8743 00	11/4” x 1”
99 8744 00	11/4” x 11/4”
99 8753 00	11/2” x 1”
99 8754 00	11/2” x 11/4”
99 8755 00	11/2” x 11/2”
99 8765 00	2” x 11/2”

RURAL ELBOW POLY x FI BSP



Product Number	Size
70 7611 00	1/2” x 1/2”
99 8621 00	3/4” x 1/2”
99 8622 00	3/4” x 3/4”
99 8631 00	1” x 1/2”
99 8632 00	1” x 3/4”
99 8633 00	1” x 1”
99 8643 00	11/4” x 1”
99 8644 00	11/4” x 11/4”
99 8654 00	11/2” x 11/4”
99 8655 00	11/2” x 11/2”
99 8665 00	2” x 11/2”
99 8666 00	2” x 2”

RURAL END CAP POLY



Product Number	Size
70 7019 00	1/2”
99 8029 00	3/4”
99 8039 00	1”
99 8049 00	11/4”
99 8059 00	11/2”
99 8069 00	2”

RURAL NUT ASSEMBLY



Product Number	Size
99 8702 00	20 to 3/4”
99 8703 00	25 to 1”
99 8704 00	32 to 11/4”
99 8705 00	40 to 11/2”
99 8706 00	50 to 2”

RURAL WALL PLATE ELBOW POLY x FI BSP

Product Number	Size
99 8229 00 (Brass)	1” x 3/4”
99 8219 01 (Plastic)	3/4” x 1/2”
99 8239 01 (Plastic)	1″ x 1/2″
99 8229 01 (Plastic)	1” x 3/4”

BLANKING SET FOR RURAL AND METRIC  FITTINGS

Product Number	Size
97 7022 00	3/4”
97 7033 00	1”
97 7044 00	11/4”
97 7055 00	11/2”
97 7066 00	2”
97 7077 00	63mm

RURAL REPAIR KIT

Product Number	Size
99 8132 50	1”
99 8143 50	1-1/4″
99 8154 50	1-1/2”
99 8165 50	2”

O-RING (RURAL)

Product Number	Size
40 2690 04	3/4″
40 6668 13	1″
40 2222 13	1-1/4″
48 8155 13	1-1/2″
40 7160 06	2″

BODY – JOINER (RURAL)

Product Number	Size
99 8122 01	3/4″
99 8133 01	1″
99 8144 01	1-1/4″
99 8155 01	1-1/2″
99 8166 01	2″

RURAL TAPPING SADDLE POLY x FI BSP-Zinc plated

Product Number	Size
90 8032 00	1” x 3/4”
90 8042 00	11/4” x 3/4”
90 8043 00	11/4” x 1”
90 8052 00	11/2” x 3/4”
90 8053 00	11/2” x 1”
90 8062 00	2” x 3/4”
90 8063 00	2” x 1”
40 8046 00	Stainless Steel 304 Nut & Bolt Kit (2)

RURAL TAPPING SADDLE POLY x FI BSP-Stainless Steel

Product Number	Size
90 8532 00	1” x 3/4”
90 8542 00	11/4” x 3/4”
90 8543 00	11/4” x 1”
90 8552 00	11/2” x 3/4”
90 8553 00	11/2” x 1”
90 8562 00	2” x 3/4”
90 8563 00	2” x 1”

TAPPING SADDLE (Mark 2) – Rubber Seal (RURAL)

Product Number	Size
40 8032 04	1″ x 3/4″
40 8042 04	11/4″ x 3/4″
40 8043 04	11/4″ x 1″
40 8052 04	11/2 x 3/4″
40 8063 04	11/2 x 3/4″

TAPPING SADDLE (Mark 2) – Nut & Bolt Kit (RURAL)

Product Number	Size
40 8062 00	Z/P
40 8046 00	Stainless Steel

3G® METRIC NUT ASSEMBLY (Useful to convert Rural Fittings to Metric)

Product Number	Size
70770200	3/4” to 20
70770300	1” to 25
70770400	1-1/4” to 32
70770500	1-1/2” to 40
70770600	2” to 50
70770700	63

Philmac Rural Compression Fittings

Brochure

Philmac Rural Compression Fittings

Range

How to install Philmac Rural Compression Fittings

Built for dependable connections on rural and stock watering systems, the Philmac Rural Compression Fitting is purpose-designed for rural poly (green stripe) PE pipe. With tool-free assembly and no pipe chamfering required, it speeds up installs while maintaining a strong, leak-free seal. The rugged, UV-stabilised body stands up to harsh Australian conditions, making it ideal for farms, water transfer, troughs, and property reticulation. Australian Made engineering means consistent quality, easy handling, and fewer callbacks.

Key Features

Fast, simple assembly – insert pipe and hand-tighten; no special tools required

Secure, leak-free seal – proven design for consistent performance in rural systems

Rural poly compatibility – engineered specifically for green-stripe PE pipe (nominal bore)

UV and corrosion resistant – suitable for above-ground and exposed environments

Robust construction – high-grade polypropylene, built for tough conditions

Applications & Benefits

Applications

• Stock watering networks and trough connections
• Farm water reticulation and property supply
• Irrigation (broadacre and horticulture)
• General water transfer and pump connections
• Repairs, extensions, and maintenance of rural poly lines

Benefits

• Speed & ease – hand-tight install saves time and labour
• Reliability – strong grip and seal reduce leaks and call-backs
• Durability – resists UV, chemicals typical of farm environments, and mechanical stress
• Versatility – available in tees, elbows, couplings, end caps, adapters, and more

Technical Specifications

Size Range: ¾”, 1″, 1¼”, 1½”, 2″ (Rural/Imperial nominal bore)

Pipe Type: Rural poly (green stripe) PE pipe

Pressure Rating: Up to PN12.5 (typical) — dependent on size and system; verify per SKU

Material: High-grade UV-stabilised polypropylene; stainless/engineering polymer components where applicable

Installation Guide

1. Cut pipe square and ensure the end is clean and free from damage.
2. Insert the pipe fully into the fitting body.
3. Hand-tighten the nut until firm. No pipe chamfering or specialist tools are required.
4. Pressurise and test the line as per best practice and local guidelines.

For detailed diagrams, torque guidance (if applicable), and troubleshooting watch the product installation step-by-step video.
